Full Automatic Powerful Roller Conveying Cartons Case Box Strapping Machine

Full Automatic Powerful Roller Conveying Cartons Case Box Strapping Machine

Overview Product Description Customized arch full automatic powerful roller conveying cartons case box PP strapping mach
SHARE

Description

Overview
Basic Info.
Model NO. UDB-102A
Strapping Mode Welding Type
Packaging Material Plastic
Driven Type Electric
Structure Side Strapping
City Qingdao
Area Huangdao
Province Shandong
Transport Package Wooden Case
Specification L 1580 mm x W 620 mm x H 1418 mm
Trademark UCPACK
Origin China
HS Code 8422400090
Production Capacity 100 Sets/ Month
Product Description
Product Description

Customized arch full automatic powerful roller conveying cartons case box PP strapping machine
UCR-102A is one of full automatic strapping machine with powerful roller conveyor.Will pack cartons automaticaly. 1*2*3 straps adjustable by the photo sensor. And arch size of strapping machine can be customized according to your products width, height.

Full Automatic Powerful Roller Conveying Cartons Case Box Strapping Machine

Product Parameters
ModelUDB-102A
Arch SizeW 800mm × H 600mm
Pack Size Min.W 210mm × H 80mm
Speed≤ 2.5 sec/strap
Tension0-60kg
Worktable Height750mm
Strap9-15mm width0.55-1.2mm thicknessPP strap
Strap RollW: 160-190mm;Inner diameter: 200-210mm;Outside diameter: 400-450mm.
Sealing MethodHeating Element
Control SystemPLC Control
VoltageAC380V 3ph 50/60Hz
Power1.4kw/5A
Noise≤ 75 dB(A)
Machine SizeL1580mm x W620mm x H1418mm
Machine Weight280kg
Options• Enlarged Arch Size; • Pneumatic Operated Top Press; • Infeed and Outlet Conveyor; • Strap Numbers Per Package; • Voltage

Full Automatic Powerful Roller Conveying Cartons Case Box Strapping Machine

Detailed PhotosControl panel;Easy to operate;English language or other language optional;Open type powerful roller conveyor;Easy to maintence;
Internal structure;380V motor;3 motors;Photo sensor;Adjustable sensor distance to realize packing performance;Arch size adjustable;According to the products size;Packaging & Shipping

Standard sea-worthy wooden case.

Full Automatic Powerful Roller Conveying Cartons Case Box Strapping Machine

Certifications

CE certification of strapping machine;

Full Automatic Powerful Roller Conveying Cartons Case Box Strapping Machine


Full Automatic Powerful Roller Conveying Cartons Case Box Strapping Machine

Company Profile

Qingdao Youchuang Packaging Equipment Co,Ltd.is a professional enterprise specializing in researching and developing , producing and marketing machinery,12 years of R&D and manufacturing experience, focusing on R&D, manufacturing,and technical services of automated packaging equipment and Custom conveyor line, providing professional technical solutions. We provide shrinking wrap machine, strapping machine, vacuum packaging machine, stretch wrapping machine, palletizer machine, various kinds conveyors, automated custom machine, etc. , with high automation and smart , according to customer requirements .Due to our high- efficient, automatic and applied packing machines, we are trusted and praised by our customers in the process of designing, manufacturing, selling, and after-sales service, based on the belief of "high-quality products, perfect service, and reasonable price."We believe that the spirit of "Specialty, Innovation, Practicism and Timeliness" and customers' trust will absolutely lead our company to success.
